0.25mm Feeler Gauge Shim Stock Roll - Carbon Steel 12.7mm x 5m

£8.70

Fast Turn Around Time on all our products.

Flat rate shipping available on all orders.

High Quality Shim Stock with international material specifications.

Pickup available at Shim Stock Metals UK

Usually ready in 24 hours

0.25mm Feeler Gauge Shim Stock Roll - Carbon Steel 12.7mm x 5m

Default Title

American Express
Apple Pay
Diners Club
Discover
Google Pay
Maestro
Mastercard
PayPal
Visa
PRODUCT INFORMATION
PRODUCT INFORMATION

Precision-engineered for demanding applications, this feeler gauge stock roll is made from cold-rolled, hardened carbon spring steel (Grade 1.1274). Designed for maximum accuracy, it’s ideal for measuring tolerances, aligning components, and setting up tools in mechanical and industrial environments.

The strip is conveniently stored in a practical plastic dispenser — simply pull it out like a tape measure and cut to the desired length. Thickness is clearly marked along the strip for quick and easy identification.

0.25mm Feeler Gauge Stock Roll – Carbon Steel (1.1274) – 12.7mm x 5m

Shim Thickness 0.25mm (0.010")
Shim Width 12.7mm (0.5")
Shim Material Length 5000mm (5m)
Material Grade 1.1274
Tensile Strength F2000–2200 N/mm²
  • Material: Cold-rolled, hardened carbon steel (Grade 1.1274)
  • Size: 12.7mm width x 5m length
  • Thickness: Available in precision-ground sizes, continuously marked from 0.01mm upwards
  • Form: Supplied in a durable dispenser for easy storage and dispensing
  • Usage: Cut-to-length strip for flexible use across applications
  • Properties: Hard, magnetic, high spring tension

Feeler Gauge Stock Applications:

  1. Aligning machinery and workpieces
  2. Measuring gaps and tolerances
  3. Tool setup and adjustment
  4. Levelling and spacing in mechanical engineering
  5. Split testing and calibration
